5 axis cnc
- High quality resin sand cast iron
- Taiwan main axis
- Taiwan ball screw and lock nut
- Taiwan booster cylinder
- NSK bearing in Japan
- German R + W coupling
- Automatic lubrication system
- Selection of chip conveyor
Introduction
Main features of 5-axis CNC
High-precision vertical CNC machining center is a multifunctional industrial equipment developed for precision machining needs, suitable for precision manufacturing of complex components in various fields. The equipment adopts an intelligent CNC system, which can perform efficient and precise machining of metals, engineering plastics and composite materials. Its vertical spindle layout gives the equipment a variety of processing possibilities, which can not only complete basic drilling operations, but also perform precision milling of complex three-dimensional surfaces. The space-saving structure and rigid body design are particularly suitable for production environments with limited operating area but strict machining accuracy requirements.
High-speed spindle unit: supports high-power cutting operation, significantly improves material removal rate, and effectively compresses production cycle
Intelligent CNC platform: integrates a new generation of CNC core, with complex trajectory calculation capabilities and user-friendly programming interface
Rigid anti-vibration bed: adopts heavy-duty structural design to suppress processing vibration and ensure long-term processing stability
Tool automatic management system: equipped with a quick tool change system (ATC) to shorten non-processing time
Micron-level precision guarantee: high repeatability positioning accuracy to meet ultra-precision processing requirements
Intelligent chip removal system: integrated multi-directional coolant injection and spiral chip removal device to keep the processing area clean
Human-machine interaction Mutual optimization: Configure graphical touch panel and status monitoring system to improve operational convenience
Industry solutions:
Aviation industry: Processing and manufacturing of precision structural parts, engine parts, and aircraft load-bearing frames
Automobile manufacturing: Mass production of key components of powertrain and precision parts of transmission system
Medical equipment production: Precision cutting of implants and core components of high-precision testing instruments
Mold manufacturing industry: Cavity processing of precision injection molds, die-casting molds, and stamping molds
Microelectronics manufacturing: High-finish processing of semiconductor equipment components and high-density connectors
Comprehensive machining field: Suitable for composite processing needs of military equipment, engineering machinery and other industries
| Specifications | Unit | VMC1580 | VMC1370 | VMC1270 | VMC1160 |
| X-axis travel | mm | 1500 | 1300 | 1200 | 1100/1000 |
| Y-axis travel | mm | 800 | 700 | 700 | 600 |
| Z-axis travel | mm | 700 | 700 | 600 | 600 |
| Table size（L*degrees） | mm | 1700×800 | 1360×700 | 1300×700 | 1200×600 |
| Maximum table load | kg | 1500 | 1400 | 1300 | 1000/800 |
| T-slot(slot number*width*pitch) | mm | 5×22×135 | 5×22×140 | 5×22×140 | 5×18×100 |
| Spindle taper | - | BT50 | BT50 | BT40/BT50 | BT40 |
| Spindle power | kw | 15-18.5 | 15-18.5 | 11 | 11-15 |
| Maximum spindie speed | rpm | 6000/8000 | 6000/8000 | 6000/8000 | 8000/10000 |
| Rapid traverse(X/Y/Z) | m/min | 2012/12/12 | 24/24/16 | 36/36/36 | 36/36/24 |
| Diameter of XYZ screw rod | mm/min | 6310/5010 | 6310/5010 | 6310/5010 | 4012/4016 |
| Feed motor | NM | 25/32/25 | 25/25/25 | 25/25/25 | 20/20/20 |
| Spindle nose to table | mm | 130-870 | 160-860 | 160-760 | 140-740/130-680 |
| Spindle center to columnsurface distance rail | mm | 810 | 780 | 750 | 650 |
| X-axis rail | mm | 55pin roller | 45pin roller | 45pin roller | 45pin roller |
| Y axis rail | mm | 45*4pin roller | 45*4pin roller | 55pin roller | 45pin roller |
| Z-axis orbit | mm | 55Roller/Hard Rail | 55pin roller | 45pin roller | 45Roller/Hard Rail |
| Positioning accuracy | mm | ±0.0075 | ±0.0075 | ±0.0075 | ±0.0075 |
| Repeat accuracy | mm | ±0.005 | ±0.005 | ±0.005 | ±0.005 |
| Machine weight.(about) | t | 13 | 10 | 8 | 6.9 |
| Dimensions | m | 4.3×3.2×3.1 | 3.87×3.17×2.92 | 3.75×2.28×2.4 | 3.4×2.5×3.0 |
