High-Precision Gantry Milling Machine for Large-Scale Metalworking

Introduction

The High-Precision Horizontal Machining Center is a state-of-the-art CNC machine designed to meet the rigorous demands of large-scale metalworking applications. Featuring a horizontal spindle layout, this machining center offers exceptional stability and precision, making it ideal for high-volume production and complex machining tasks. Equipped with advanced control systems, it allows for enhanced machining accuracy and reliability, ensuring superior surface finishes and tight tolerances across a wide range of metal materials. With its robust construction and versatile capabilities, this machine excels in industries such as automotive, aerospace, and heavy machinery manufacturing.

Key Features:

  • Horizontal Spindle Design: Ensures efficient chip removal and consistent cutting performance.
  • High-Speed CNC Control: Allows for precise control and complex multi-axis operations.
  • Heavy-Duty Construction: Designed to handle large and heavy workpieces, ensuring stability and precision under load.
  • Advanced Tool Changer: Minimizes downtime by allowing for fast tool changes, improving productivity.
  • Superior Accuracy: Achieves micron-level precision for highly detailed components.
  • Automated Features: Includes automatic tool measurement and error compensation for reduced operator intervention and consistent results.
  • Versatile Applications: Ideal for complex parts that require multiple machining processes such as drilling, milling, and boring.

Applications:

  • Automotive Manufacturing: For producing engine blocks, transmission parts, and other critical automotive components.
  • Aerospace Industry: Ideal for machining complex, high-precision parts for aircraft and spacecraft.
  • Heavy Machinery: Perfect for producing large-scale components for construction equipment and industrial machinery.
  • Oil & Gas: Machining critical components used in drilling, extraction, and transportation of oil and gas.
  • Tooling and Die Manufacturing: Precision machining for molds, dies, and tooling used in various industries.

Specifications Unit TH-63/63S TH-80 TH-100
X-axis travel mm 1050 1600 1600
Y-axis travel mm 750 1000 1000
Z-axis travel mm 900 1000 1000
Number of workbenches Individual 1/2 1 1
Workbench indexing -
Distance from spindle face to center of worktable mm 130-1030 200-1200 200-1200
Distance from spindle center to table surface mm 120-870/0-750 120-1120 120-1120
Spindle speed rpm 6000 6000 6000
Spindle taper - BT50-190 BT50-190 BT50-190
Workbench area mm 630x700 800 x 800 1000x1000
Maximum load of worktable kg 950 1500 1500
Maximum rotary diameter of workpiece mm 1380/950 1800 1800
X-Axis Fast Displacement m/min 30 24 24
Y-Axis Fast Displacement m/min 30 24 24
Z-Axis Fast Displacement m/min 30 24 24
Cutting feed mm/min 10-10000 10-10000 10-10000
Machine weight.(about) T 8.0/9.5 9.5
